3061826
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
TERM BLK PLUG 4POS 8.2MM GRAY
PDF
/
Buying Options
Total Price: USD $3.96
Unit Price: USD $3.96
≥1 USD $3.96
Inventory: 90
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Width 8.2mm
Length 3.929 99.80mm
Height 51.0032mm
Technical
Fastening Method SCREW
Wire Cross Section 2.5 mm2
Stripping Length 12mm
Current - IEC 41A
Wire Gauge or Range - mm2 0.5-10mm2
Safety Approval CSA; CUL; GL; GOST; UL
Number of Ways 3
Voltage - IEC 1kV
Wire Gauge or Range - AWG 8-20 AWG
Number of Decks 1
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 20 AWG
Current 40A
Number of Levels 1
Voltage 600V
Housing Color Gray
Termination Style Plug Receptacles, Push In, Spring
Current Rating 41A
Reach Compliance Code unknown
Voltage - Rated 1kV
Number of Rows 1
Color Grey
Min Operating Temperature -60°C
Max Operating Temperature 125°C
Number of Positions 4
Type Plug Connection
Connector Type Push-In
ECCN Code EAR99
Termination Plug
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series CLIPLINE PT
Published 2013
Physical
Material - Insulation Polyamide (PA), Nylon
Mounting Type DIN Rail
Mount DIN Rail
Supply Chain
Factory Lead Time 7 Weeks
