RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description CLIPLINE RSC RoHS Compliant Polyamide (PA) Nylon Screw Terminal Block NEMA Open Construction UL94V-0 26AWG 45A 600V
PDF
/
Inventory: 1094
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount DIN Rail
Mounting Type DIN Rail
Material - Insulation Polyamide (PA), Nylon

Technical

Series CLIPLINE RSC
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type NEMA Open Construction
Number of Positions 8
Color Grey
Termination Style Screw
Housing Color Gray
Voltage 600V
Number of Levels 1
Current 45A
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 8 AWG
Voltage - UL 600V
Wire Gauge or Range - AWG 8-26 AWG
Voltage - IEC 800V
Wire Gauge or Range - mm2 0.1-6mm2
Current - IEC 57A

Dimensions

Height 37.0078mm
Length 2.098 53.30mm
Terminal Width 13.0mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
