3042719 image
Favorite
3042719 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description DIN Rail Terminal Blocks ST 4/1P
PDF
/
Buying Options
Total Price: USD $2.18
Unit Price: USD $2.1824
≥1 USD $2.1824
≥10 USD $2.12696
≥100 USD $1.98792
≥500 USD $1.828904
≥1000 USD $1.689741
≥3000 USD $1.610224
Inventory: 70
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 7 Weeks

Physical

Mount DIN Rail
Mounting Type DIN Rail
Housing Material Polyamide
Weight 7.930014g
Material - Insulation Polyamide (PA), Nylon

Technical

Published 2011
Series CLIPLINE ST
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Plug
ECCN Code EAR99
Type Plug Connection
Number of Positions 2
Color Grey
Number of Rows 1
Voltage - Rated 800V
Additional Feature STANDARD: UL 94V-0, PA
HTS Code 8536.69.40.40
Current Rating 32A
Termination Style Plug Receptacles, Push In, Spring
Approval Agency CB, CSA, UL, VDE, cULus
Housing Color Gray
Voltage 600V
Number of Levels 1
Current 30A
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 10 AWG
Wire/Cable Gauge 10 AWG
Number of Decks 1
Wire Gauge or Range - AWG 10-28 AWG
Voltage - IEC 800V
Number of Ways 2
Safety Approval CB; CSA; CUL; EAC; UL; VDE
Wire Gauge or Range - mm2 0.08-6mm2
Current - IEC 32A
Stripping Length 10mm
Fastening Method SPRING LOADED

Dimensions

Height 43.9928mm
Length 2.177 55.30mm
Width 6.2mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
