3042007
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
DIN Rail Terminal Blocks ST 2.5-4L/2P
PDF
/
Buying Options
Total Price: USD $19.31
Unit Price: USD $19.31327
≥1 USD $19.31327
≥10 USD $18.220069
≥100 USD $17.188745
≥500 USD $16.21579
≥1000 USD $15.297916
Inventory: 6557
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount DIN Rail
Mounting Type DIN Rail
Housing Material Polyamide
Weight 23.639987g
Material - Insulation Polyamide (PA), Nylon
Technical
Published 2011
Series CLIPLINE ST
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Plug
ECCN Code EAR99
Type Plug Connection
Number of Positions 12
Color Grey
Voltage - Rated 500V
Current Rating 24A
Termination Style Plug Receptacles, Push In, Spring
Housing Color Gray
Voltage 300V
Number of Levels 4
Current 10A
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 12 AWG
Wire Gauge or Range - AWG 12-28 AWG
Voltage - IEC 250V
Wire Gauge or Range - mm2 0.08-4mm2
Stripping Length 10mm
Dimensions
Height 66.4972mm
Length 4.744 120.50mm
Width 5.2mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
