3040685
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
DIN Rail Terminal Blocks STTB 2.5/ 2P-PV-BU
PDF
/
Inventory: 4006
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Width 5.2mm
Length 2.815 71.50mm
Height 54.991mm
Technical
Stripping Length 10mm
Current - IEC 22A
Wire Gauge or Range - mm2 0.08-4mm2
Voltage - IEC 500V
Wire Gauge or Range - AWG 12-28 AWG
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 28 AWG
Current 20A
Number of Levels 2; Connected
Voltage 300V
Housing Color Blue
Termination Style Plug Receptacles, Push In, Spring
Current Rating 22A
Voltage - Rated 500V
Number of Positions 4
Type Plug Connection
ECCN Code EAR99
Termination Plug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series CLIPLINE STTB
Published 2010
Physical
Material - Insulation Polyamide (PA), Nylon
Weight 10.650009g
Housing Material Polyamide
Mounting Type DIN Rail
Mount DIN Rail
Supply Chain
Factory Lead Time 4 Weeks
