3002973
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
DISTRIBUTION BLOCK VIOLET
PDF
/
Buying Options
Total Price: USD $3.31
Unit Price: USD $3.3088
≥1 USD $3.3088
≥10 USD $3.21992
≥100 USD $3.0096
≥500 USD $2.768832
≥1000 USD $2.55816
≥3000 USD $2.437794
Inventory: 123
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Terminal Width 12.5mm
Height (Max) 1.079 27.40mm
Length 0.850 21.60mm
Technical
Stripping Length 10mm
Current - IEC 17.5A
Wire Gauge or Range - mm2 0.14-1.5mm2
Voltage - IEC 450V
Current - UL 15A
Wire Gauge or Range - AWG 14-26 AWG
Voltage - UL 300V
Number of Levels 1
Housing Color Violet
Termination Style Push In, Spring
Number of Positions 6
Type Middle
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Block of 3
Series CLIPLINE PTFIX
Published 2017
Operating Temperature -60°C~130°C
Physical
Material - Insulation Polyamide (PA), Nylon
Mounting Type DIN Rail
Supply Chain
Factory Lead Time 6 Weeks
