3002893
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
CLIPLINE PTFIX RoHS Compliant 2017 Block of 3 Terminal Block Middle 14-26AWG -60C~130C 15A 450V
PDF
/
Buying Options
Total Price: USD $1.69
Unit Price: USD $1.6896
≥1 USD $1.6896
Inventory: 93
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Terminal Width 12.5mm
Height (Max) 0.736 18.70mm
Length 0.850 21.60mm
Technical
Stripping Length 10mm
Current - IEC 17.5A
Wire Gauge or Range - mm2 0.14-1.5mm2
Voltage - IEC 450V
Current - UL 15A
Wire Gauge or Range - AWG 14-26 AWG
Voltage - UL 300V
Number of Levels 1
Housing Color Black
Termination Style Push In, Spring
Number of Positions 6
Type Middle
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Block of 3
Series CLIPLINE PTFIX
Published 2017
Operating Temperature -60°C~130°C
Physical
Material - Insulation Polyamide (PA), Nylon
Mounting Type Direct Mount
Supply Chain
Factory Lead Time 6 Weeks
