3001874
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
POTENTIAL DISTRIBUTOR 12-26AWG
PDF
/
Inventory: 1122
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type DIN Rail
Material - Insulation Polyamide (PA), Nylon
Technical
Series CLIPLINE PT
Part Status Active
Type Marshalling Connector
Number of Positions 16
Color Grey
Termination Style Push In, Spring
Housing Color Gray
Number of Levels 4
Voltage - UL 300V
Wire Gauge or Range - AWG 14-26 AWG
Voltage - IEC 250V
Wire Gauge or Range - mm2 0.14-2.5mm2
Current - IEC 10A
Stripping Length 10mm
Dimensions
Length 2.520 64.00mm
Height (Max) 2.480 63.00mm
Terminal Width 8.3mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Alternative Model
