Package /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description Pluggable Terminal Blocks UMSTBVK 2.5/ 6-ST-5.
PDF
/
Buying Options
Total Price: USD $15.69
Unit Price: USD $15.685592
≥1 USD $15.685592
≥10 USD $14.797734
≥100 USD $13.960113
≥500 USD $13.169923
≥1000 USD $12.424455
Inventory: 8826
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Contact Material Tin
Mount DIN Rail
Mounting Type DIN Rail
Housing Material Polyamide
Weight 21.180014g
Material - Insulation Polyamide (PA), Nylon

Technical

Published 2011
Series COMBICON UMSTBVK
Feature Retention Latches
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
ECCN Code EAR99
Connector Type Plug, Screw
Type Plug Connection - Ganged
Number of Positions 6
Number of Rows 1
Voltage - Rated 320V
Additional Feature PA, 94V-0
Pitch 5.08mm
Current Rating 12A
Termination Style Plug Receptacles, Screw
Housing Color Green
Voltage 300V
Number of Levels 1
Current 10A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 24 AWG
Number of Decks 1
Wire Gauge or Range - AWG 12-30 AWG
Number of Ways 6
Safety Approval UL
Wire Gauge or Range - mm2 0.2-2.5mm2
Stripping Length 7mm
Wire Cross Section 2.5 mm2

Dimensions

Height 43.5102mm
Length 1.260 32.00mm
Width 43.5mm
Terminal Width 42.5mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
