1803060 image
Favorite
1803060 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description TERM BLK PLUG 13POS 27.2MM GREEN
PDF
/
Inventory: 1140
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-2

Dimensions

Terminal Width 27.2mm
Height (Max) 1.181 30.00mm
Length 3.046 77.36mm

Technical

Rated Voltage 320V
Wire Cross Section 2.5 mm2
Stripping Length 7mm
Current - IEC 12A
Wire Gauge or Range - mm2 0.2-2.5mm2
Safety Approval UL
Number of Ways 13
Voltage - IEC 300V
Wire Gauge or Range - AWG 12-30 AWG
Number of Decks 1
Number of Levels 1
Housing Color Green
Termination Style Plug Receptacles, Screw
HTS Code 8536.69.40.40
Additional Feature PA, 94V-2
Number of Rows 1
Number of Positions 13
Type Plug Connection - Ganged
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Mating Flange
Series COMBICON MSTBVK
Published 2016

Physical

Material - Insulation Polyamide (PA), Nylon
Mounting Type DIN Rail

Supply Chain

Factory Lead Time 4 Weeks
