RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description Pluggable Terminal Blocks MSTBVK2.5/5-G-5.08
PDF
/
Buying Options
Total Price: USD $9.9
Unit Price: USD $9.9
≥1 USD $9.9
≥10 USD $9.6272
≥100 USD $8.99712
≥500 USD $8.277368
≥1000 USD $8.1224
Inventory: 199
Minimum: 1
-
+

Technical Details

Compliance

Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-2

Dimensions

Terminal Width 27.2mm
Width 37mm
Length 1.060 26.92mm
Height 29.9974mm

Technical

Stripping Length 7mm
Wire Gauge or Range - mm2 0.2-2.5mm2
Safety Approval UL
Number of Ways 5
Wire Gauge or Range - AWG 12-30 AWG
Number of Decks 1
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 30 AWG
Current 12A
Number of Levels 1
Max Current Rating 12A
Voltage 300V
Housing Color Green
Number of Contacts 5
Termination Style Plug Receptacles, Screw
Current Rating 12A
Reach Compliance Code unknown
Pitch 5.08mm
Additional Feature PA, 94V-2
Voltage - Rated 320V
Number of Rows 1
Type Plug Connection - Ganged
Connector Type Plug, Screw
ECCN Code EAR99
Termination Screw
Part Status Active
Pbfree Code yes
Series COMBICON MSTBVK
Published 2011

Physical

Material - Insulation Polyamide (PA), Nylon
Weight 210g
Housing Material Polyamide
Mounting Type DIN Rail
Mount Cable, DIN Rail
Contact Material Tin

Supply Chain

Factory Lead Time 7 Weeks
