1788169
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
Pluggable Terminal Blocks UMSTBVK 2 5/ 7-G-5 0
PDF
/
Buying Options
Total Price: USD $16.76
Unit Price: USD $16.764
≥1 USD $16.764
≥10 USD $16.30464
≥100 USD $15.23808
≥500 USD $14.019104
≥1000 USD $13.756582
Inventory: 155
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Tin
Mount DIN Rail
Mounting Type DIN Rail
Housing Material Polyamide
Weight 211.000001g
Material - Insulation Polyamide (PA), Nylon
Technical
Published 2011
Series COMBICON UMSTBVK
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
ECCN Code EAR99
Connector Type Plug, Screw
Type Plug Connection - Ganged
Number of Rows 1
Voltage - Rated 320V
Additional Feature PA, 94V-2
HTS Code 8536.69.40.40
Pitch 5.08mm
Reach Compliance Code unknown
Current Rating 12A
Termination Style Plug Receptacles, Screw
Number of Contacts 7
Housing Color Green
Voltage 300V
Max Current Rating 12A
Number of Levels 1
Current 12A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 12 AWG
Number of Decks 1
Wire Gauge or Range - AWG 12-30 AWG
Number of Ways 7
Safety Approval UL
Wire Gauge or Range - mm2 0.2-2.5mm2
Stripping Length 7mm
Wire Cross Section 2.5 mm2
Dimensions
Height 50.3936mm
Length 1.460 37.08mm
Width 43.5mm
Terminal Width 42.5mm
Compliance
Material Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
