RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description Pluggable Terminal Blocks UMSTBVK 2 5/10-GF-5
PDF
/
Buying Options
Total Price: USD $23.15
Unit Price: USD $23.1528
≥1 USD $23.1528
Inventory: 130
Minimum: 1
-
+

Technical Details

Compliance

Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-2

Dimensions

Terminal Width 42.5mm
Width 62.12mm
Length 2.446 62.12mm
Height 50.3936mm

Technical

Wire Cross Section 2.5 mm2
Stripping Length 7mm
Wire Gauge or Range - mm2 0.2-2.5mm2
Safety Approval UL
Number of Ways 10
Wire Gauge or Range - AWG 12-30 AWG
Number of Decks 1
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 30 AWG
Current 12A
Number of Levels 1
Max Current Rating 12A
Voltage 300V
Housing Color Green
Number of Contacts 10
Termination Style Plug Receptacles, Screw
Current Rating 12A
Reach Compliance Code unknown
Pitch 5.08mm
HTS Code 8536.69.40.40
Additional Feature PA, 94V-2
Voltage - Rated 320V
Number of Rows 1
Type Plug Connection - Ganged
Connector Type Plug, Screw
ECCN Code EAR99
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Mating Flange
Series COMBICON UMSTBVK
Published 2010

Physical

Material - Insulation Polyamide (PA), Nylon
Weight 211.000001g
Housing Material Polyamide
Mounting Type DIN Rail
Mount Cable, DIN Rail
Contact Material Tin

Supply Chain

Factory Lead Time 4 Weeks
