CBB70LS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
CBB ROHS3Compliant Polyamide (PA66) Nylon 6/6 Bolt and Nut Terminal Block Bus Bar - Terminals 2/0-8AWG -50C~105C 175A 1kV
PDF
/
Inventory: 2721
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type DIN Rail
Material - Insulation Polyamide (PA66), Nylon 6/6
Technical
Operating Temperature -50°C~105°C
Series CBB
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Bus Bar - Terminals
Number of Positions 2
Termination Style Bolt and Nut
Housing Color Gray
Number of Levels 1
Voltage - UL 600V
Wire Gauge or Range - AWG 2/0-8 AWG
Current - UL 175A
Voltage - IEC 1kV
Wire Gauge or Range - mm2 6-70mm2
Current - IEC 192A
Dimensions
Length 3.622 92.00mm
Height (Max) 2.146 54.50mm
Terminal Width 38.0mm
Compliance
Material Flammability Rating UL94 V-0, UL94 V-2
RoHS Status ROHS3 Compliant
