CBB150LS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
CBB ROHS3Compliant Polyamide (PA66) Nylon 6/6 Bolt and Nut Terminal Block Bus Bar - Terminals 300kcmil-8AWG -50C~105C 285A 1kV
PDF
/
Inventory: 2984
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0, UL94 V-2
Dimensions
Terminal Width 48.0mm
Height (Max) 2.146 54.50mm
Length 4.331 110.00mm
Technical
Current - IEC 309A
Wire Gauge or Range - mm2 16-150mm2
Voltage - IEC 1kV
Current - UL 285A
Wire Gauge or Range - AWG 300kcmil-8 AWG
Voltage - UL 600V
Number of Levels 1
Housing Color Gray
Termination Style Bolt and Nut
Number of Positions 2
Type Bus Bar - Terminals
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series CBB
Operating Temperature -50°C~105°C
Physical
Material - Insulation Polyamide (PA66), Nylon 6/6
Mounting Type DIN Rail
Supply Chain
Factory Lead Time 7 Weeks
