1936830000
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description
Omnimate Power WGK RoHS Compliant 2013 CE CSA IEC cURus Terminal Block 2 Piece UL94V-0 20AWG 85A 600V
PDF
/
Inventory: 7461
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Panel Thickness 0.098 ~ 0.236 2.5 ~ 6.0mm
Width 0.476 12.10mm
Length 63.5mm
Height 40.4mm
Technical
Rear Panel Wire Connection Bolt/Screw Clamp - Wire Entry 90° to Panel
Front Panel Wire Connection Bolt/Screw Clamp - Wire Entry 90° to Panel
Safety Approval UL; CSA
Number of Ways 1
Terminal and Terminal Block Type MODULAR TERMINAL BLOCK
Number of Decks 1
Wire Gauge (Min) 4 AWG
Wire Gauge (Max) 20 AWG
Current 85A
Number of Circuits 2
Voltage 600V
Wire Gauge 4-20 AWG
Housing Color Grey
Approval Agency CE, CSA, IEC, cURus
Current Rating 76A
HTS Code 8536.69.40.40
Additional Feature STANDARD: UL 94V-0
Voltage - Rated 6kV
Number of Rows 1
Color Gray
ECCN Code EAR99
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Omnimate Power WGK
Published 2013
Physical
Panel Mount Type 2 Piece
Mount Panel
Supply Chain
Factory Lead Time 11 Weeks
