1635830000
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description
Terminal Block Panel Mount
PDF
/
Inventory: 8219
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 2.974 75.54mm
Length 75.6mm
Height 28mm
Technical
Rear Panel Wire Connection Quick Connect - 0.110 (2.80mm), Solder Eyelet
Front Panel Wire Connection Header, Male Pins
Current 15A
Number of Levels 1
Voltage 300V
Insulation Resistance 1MOhm
Total Number of Contacts 11
Pitch 0.200 5.08mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 1
Color Black
Number of Positions 11
Connector Type BOARD CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code yes
Feature Lock Opening
Series Omnimate SLDF
Physical
Panel Mount Type Screw Mount - Front Flange
Housing Material Plastic
Mounting Type PANEL
Contact Plating Tin
