3056226
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description
CLIPLINE RW RoHS Compliant 2013 Engagement Pin Terminal Block 2 Piece UL94V-0 115A 600V 0.039-0.236 1.0-6.0mm
PDF
/
Inventory: 1088
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Panel Thickness 0.039 ~ 0.236 1.0 ~ 6.0mm
Width 0.799 20.30mm
Technical
Rear Panel Wire Connection Bolt/Screw Clamp - Wire Entry 90° to Panel
Front Panel Wire Connection Bolt/Screw Clamp - Wire Entry 90° to Panel
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Voltage - UL 600V
Current 115A
Voltage 600V
Number of Contacts 2
Current Rating 125A
Voltage - Rated 1kV
Gender Female
Number of Rows 1
Color Gray
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code yes
Feature Engagement Pin
Series CLIPLINE RW
Published 2013
Physical
Panel Mount Type 2 Piece
Material Polyamide
Mount Through Hole
Supply Chain
Factory Lead Time 7 Weeks
