RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description Pluggable Terminal Blocks 8 Pos 7.62mm pitch Feed Through Header
PDF
/
Buying Options
Total Price: USD $14.05
Unit Price: USD $14.0536
≥1 USD $14.0536
≥10 USD $13.66904
≥100 USD $12.77496
≥500 USD $11.753016
≥1000 USD $10.858707
≥3000 USD $10.347762
Inventory: 116
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Contact Material Tin
Mounting Type PANEL
Housing Material Polyamide
Weight 17.790006g
Panel Mount Type Screw Mount - Front Flange

Technical

Published 2011
Series COMBICON DFK-PC
Feature Threaded Mating Lock
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Plug
Color Green
Number of Rows 1
Voltage - Rated 400V
Additional Feature PA, 94V-2
Pitch 0.300 7.62mm
Orientation Straight
Reach Compliance Code unknown
Current Rating 15A
Voltage 300V
Max Current Rating 15A
Number of Levels 1
Current 20A
Wire Gauge (Max) 10 AWG
Wire Gauge (Min) 24 AWG
Number of Decks 1
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Ways 8
Safety Approval UL
Number of Positions Per Level 8
Wire Cross Section 4 mm2
Front Panel Wire Connection Header, Male Pins
Rear Panel Wire Connection Quick Connect - 0.187 (4.75mm), Solder Eyelet

Dimensions

Height 37.35mm
Length 76.18mm
Width 2.999 76.18mm
Panel Thickness 0.039 ~ 0.197 1.0 ~ 5.0mm

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
