1727841
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description
Pluggable Terminal Blocks 6 Pos 7.62mm pitch Feed Through Header
PDF
/
Inventory: 1150
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Plating Tin
Mounting Type BOARD AND PANEL
Weight 22.219988g
Panel Mount Type 2 Piece, Snap Lock
Technical
Published 2011
Series COMBICON DFK-PC
Pbfree Code yes
Part Status Last Time Buy
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Number of Positions 6
Color Green
Number of Rows 1
Voltage - Rated 500V
Additional Feature PA, UL 94V0
Pitch 0.300 7.62mm
Current Rating 41A
Voltage 300V
Number of Levels 1
Current 41A
Number of Decks 1
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Ways 6
Safety Approval UL
Front Panel Wire Connection Header, Male Pins
Rear Panel Wire Connection PCB Pins - Right Angle
Dimensions
Width 2.804 71.22mm
Panel Thickness 0.039 ~ 0.118 1.0 ~ 3.0mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
