1703836
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description
Pluggable Terminal Blocks 8 Pos 10.16mm pitch Feed Thru Invert Hdr
PDF
/
Buying Options
Total Price: USD $50.71
Unit Price: USD $50.7056
≥1 USD $50.7056
≥10 USD $47.38536
≥100 USD $43.594672
≥500 USD $40.2776
Inventory: 73
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Panel Thickness 0.039 ~ 0.118 1.0 ~ 3.0mm
Width 4.817 122.36mm
Technical
Rear Panel Wire Connection Bolt/Screw Clamp - Wire Entry Parallel to Panel
Front Panel Wire Connection Header, Female Sockets
Safety Approval UL
Number of Ways 8
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Decks 1
Wire Gauge (Min) 6 AWG
Wire Gauge (Max) 20 AWG
Current 55A
Number of Levels 1
Voltage 600V
Wire Gauge 6-20 AWG
Current Rating 76A
Pitch 0.400 10.16mm
Additional Feature PA, UL 94V-0
Voltage - Rated 1kV
Number of Rows 1
Color Green
Number of Positions 8
ECCN Code EAR99
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Threaded Mating Lock, Shield Connection Front Side
Series COMBICON DFK-IPC
Published 1998
Physical
Panel Mount Type 2 Piece, Snap Lock - Front Flange
Contact Material Silver
Supply Chain
Factory Lead Time 7 Weeks
