1703522
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description
Pluggable Terminal Blocks 9 Pos 10.16mm pitch Feed Through Header
PDF
/
Inventory: 1527
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Plating Silver
Weight 119.999988g
Panel Mount Type 2 Piece, Snap Lock - Front Flange
Technical
Packaging Tape & Reel (TR)
Published 1998
Series COMBICON DFK-PC
Feature Threaded Mating Lock, Shield Connection Front Side
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color Green
Number of Rows 1
Voltage - Rated 1kV
Pitch 0.400 10.16mm
Current Rating 76A
Wire Gauge 6-20 AWG
Voltage 600V
Number of Levels 1
Current 55A
Wire Gauge (Max) 20 AWG
Wire Gauge (Min) 6 AWG
Number of Decks 1
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Ways 9
Safety Approval UL
Number of Positions Per Level 9
Front Panel Wire Connection Header, Male Pins
Rear Panel Wire Connection Bolt/Screw Clamp - Wire Entry Parallel to Panel
Dimensions
Width 4.992 126.80mm
Panel Thickness 0.039 ~ 0.118 1.0 ~ 3.0mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
