1702549
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description
Pluggable Terminal Blocks 7 Pos 10.16mm pitch Feed Thru Invert Hdr
PDF
/
Inventory: 4414
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Panel Thickness 0.039 ~ 0.118 1.0 ~ 3.0mm
Width 3.750 95.24mm
Length 95.24mm
Technical
Rear Panel Wire Connection PCB Pins - Right Angle
Front Panel Wire Connection Header, Female Sockets
Safety Approval UL
Number of Ways 7
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Decks 1
Current 5A
Number of Levels 1
Max Current Rating 76A
Voltage 600V
Current Rating 76A
Orientation Right Angle
Pitch 0.400 10.16mm
HTS Code 8536.69.40.40
Additional Feature PA, UL 94V-0
Voltage - Rated 1kV
Number of Rows 1
Color Green
Number of Positions 7
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series COMBICON DFK-IPC
Published 2011
Physical
Panel Mount Type 2 Piece, Snap Lock
Weight 24.820007g
Housing Material Polyamide
Mounting Type BOARD AND PANEL
Contact Material Silver
Supply Chain
Factory Lead Time 7 Weeks
