RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description Pluggable Terminal Blocks 5 Pos 10.16mm pitch Feed Through Header
PDF
/
Inventory: 1398
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Panel Thickness 0.039 ~ 0.118 1.0 ~ 3.0mm
Width 3.392 86.16mm
Length 86.16mm

Technical

Rear Panel Wire Connection PCB Pins - Right Angle
Front Panel Wire Connection Header, Male Pins
Safety Approval UL
Number of Ways 5
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Decks 1
Current 5A
Number of Levels 1
Max Current Rating 76A
ELV Compliant
Voltage 600V
Current Rating 76A
Depth 46.4mm
Orientation Right Angle
Pitch 0.400 10.16mm
Additional Feature PA, UL 94V-0
Voltage - Rated 1kV
Gender Female
Number of Rows 1
Color Green
Number of Positions 5
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Threaded Mating Lock, Shield Connection Feedthrough
Series COMBICON DFK-PC
Published 2005

Physical

Panel Mount Type 2 Piece, Snap Lock - Front Flange
Weight 30.01999g
Housing Material Polyamide
Mounting Type BOARD AND PANEL
Contact Material Silver

Supply Chain

Factory Lead Time 7 Weeks
