0714037
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description
CLIPLINE HDFK RoHS Compliant Engagement Pin Bolt/Screw Clamp - Wire Entry 90° to Panel Terminal Block 2 Piece UL94V-0 4AWG 230A 600V
PDF
/
Inventory: 8440
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Material Polyamide
Panel Mount Type 2 Piece
Technical
Series CLIPLINE HDFK
Feature Engagement Pin
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Color Gray
Number of Rows 1
Gender Female
Voltage - Rated 1kV
Reach Compliance Code not_compliant
Current Rating 232A
Number of Contacts 2
Wire Gauge 4/0-4 AWG
Voltage 600V
Current 230A
Wire Gauge (Max) 4 AWG
Wire Gauge (Min) 0 AWG
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Front Panel Wire Connection Bolt/Screw Clamp - Wire Entry 90° to Panel
Rear Panel Wire Connection Bolt/Screw Clamp - Wire Entry 90° to Panel
Dimensions
Length 94.5mm
Width 0.984 25.00mm
Panel Thickness 0.039 ~ 0.236 1.0 ~ 6.0mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
