0710219
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description
Pluggable Terminal Blocks 6 Pos 5.08mm pitch Feed Through Header
PDF
/
Buying Options
Total Price: USD $8.67
Unit Price: USD $8.668
≥1 USD $8.668
≥10 USD $7.70176
≥100 USD $7.027504
≥500 USD $6.738688
≥1000 USD $6.161126
≥3000 USD $5.776091
Inventory: 504
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Tin
Mount Wall
Weight 7.340003g
Panel Mount Type Screw Mount - Front Flange
Technical
Series COMBICON DFK-MSTB
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Plug
Number of Positions 6
Color Green
Number of Rows 1
Voltage - Rated 320V
Additional Feature POLYAMIDE, 94V-2
Pitch 0.200 5.08mm
Orientation Straight
Reach Compliance Code not_compliant
Current Rating 12A
Voltage 300V
Max Current Rating 12A
Number of Levels 1
Current 10A
Number of Decks 1
Terminal and Terminal Block Type MODULAR TERMINAL BLOCK
Number of Ways 6
Safety Approval UL; CSA
Wire Cross Section 2.5 mm2
Front Panel Wire Connection Header, Male Pins
Rear Panel Wire Connection Quick Connect - 0.110 (2.80mm), Solder Eyelet
Dimensions
Height 27.2mm
Length 17.5mm
Width 2.000 50.80mm
Panel Thickness 0.020 ~ 0.157 0.5 ~ 4.0mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Lead Free
