0710206
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description
Pluggable Terminal Blocks 5 Pos 5.08mm pitch Feed Through Header
PDF
/
Buying Options
Total Price: USD $4.86
Unit Price: USD $4.8576
≥1 USD $4.8576
Inventory: 137
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Panel Thickness 0.020 ~ 0.157 0.5 ~ 4.0mm
Width 1.800 45.72mm
Length 45.72mm
Height 27.2mm
Technical
Rear Panel Wire Connection Quick Connect - 0.110 (2.80mm), Solder Eyelet
Front Panel Wire Connection Header, Male Pins
Safety Approval UL; CSA
Number of Ways 5
Terminal and Terminal Block Type MODULAR TERMINAL BLOCK
Number of Decks 1
Current 10A
Number of Levels 1
Max Current Rating 12A
Voltage 300V
Current Rating 12A
Depth 29.5mm
Orientation Straight
Pitch 0.200 5.08mm
Voltage - Rated 320V
Number of Rows 1
Color Green
Number of Positions 5
Connector Type Plug
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series COMBICON DFK-MSTB
Physical
Panel Mount Type Screw Mount - Front Flange
Weight 6.540008g
Housing Material Polyamide
Mount Wall
Contact Material Tin
Supply Chain
Factory Lead Time 4 Weeks
