0710138
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description
Pluggable Terminal Blocks 13 Pos 5mm pitch Feed Through Header
PDF
/
Buying Options
Total Price: USD $10.08
Unit Price: USD $10.0848
≥1 USD $10.0848
Inventory: 126
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Panel Thickness 0.020 ~ 0.157 0.5 ~ 4.0mm
Width 3.346 85.00mm
Technical
Rear Panel Wire Connection Quick Connect - 0.110 (2.80mm), Solder Eyelet
Front Panel Wire Connection Header, Male Pins
Wire Cross Section 2.5 mm2
Number of Positions Per Level 13
Safety Approval UL; CSA
Number of Ways 13
Terminal and Terminal Block Type MODULAR TERMINAL BLOCK
Number of Decks 1
Voltage - UL 300V
Current 10A
Number of Levels 1
Voltage 300V
Current Rating 12A
Pitch 0.197 5.00mm
HTS Code 8536.69.40.40
Additional Feature POLYAMIDE, 94V-2
Voltage - Rated 320V
Number of Rows 1
Color Green
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series COMBICON DFK-MSTB
Physical
Panel Mount Type Screw Mount - Front Flange
Mounting Type BOARD
Contact Plating Tin
Supply Chain
Factory Lead Time 5 Weeks
