8019960000

Weidmüller
RoHS
RoHS RoHS compliant
Package Module
Category Connectors, Interconnects / Terminal Blocks - Interface Modules
Description INTERFACE MOD DSUB MALE 37POS
PDF
/
Inventory: 7074
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC No SVHC

Dimensions

Width 3.425 87.00mm
Length 3.150 80.00mm
Height 80mm

Technical

Control Side Cable Retainer Jackscrew Socket, 4-40 Mating Thread
Positions / Poles 37
Control Side Connection D-Sub, Male
Process Side Connection Terminal Blocks - Screw Connection
Stripping Length 6mm
Contact Current Rating 1.5A
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 26 AWG
Termination Type SOLDER
Shell Size 4/C
Body/Shell Style PLUG
Wire Gauge 16-26 AWG
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency CE
Current Rating 1.5A
Total Number of Contacts 37
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Voltage - Rated 125VAC 150VDC
Connector Type D SUBMINIATURE CONNECTOR
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Label Holder
Series RS
Published 2008
Operating Temperature 0°C~55°C

Physical

Package / Case Module
Mounting Type BOARD AND PANEL

Supply Chain

Factory Lead Time 12 Weeks
