8019940000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Interface Modules
Description
INTERFACE MOD DSUB MALE 15POS
PDF
/
Inventory: 3767
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3.425 87.00mm
Length 1.772 45.00mm
Height 80mm
Technical
Control Side Cable Retainer Jackscrew Socket, 4-40 Mating Thread
Positions / Poles 15
Control Side Connection D-Sub, Male
Process Side Connection Terminal Blocks - Screw Connection
Stripping Length 6mm
Contact Current Rating 1.5A
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 26 AWG
Termination Type SOLDER
Shell Size 2/A
Body/Shell Style PLUG
Wire Gauge 16-26 AWG
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency CE
Current Rating 1.5A
Total Number of Contacts 15
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Voltage - Rated 125VAC 150VDC
Connector Type D SUBMINIATURE CONNECTOR
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Label Holder
Series RS
Published 2008
Operating Temperature 0°C~55°C
Physical
Mounting Type BOARD AND PANEL
Supply Chain
Factory Lead Time 8 Weeks
