2962780
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Terminal Blocks - Interface Modules
Description
Interface Modules UM 45-D15SUB/S
PDF
/
Buying Options
Total Price: USD $161.67
Unit Price: USD $161.6736
≥1 USD $161.6736
Inventory: 55
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount DIN Rail
Package / Case Module
Material Polyamide
Weight 49.860007g
Technical
Operating Temperature -20°C~50°C
Published 2011
Series VARIOFACE, UM
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Connector Type D-Sub
Gender Male
Voltage - Rated 125V
Depth 45mm
Current Rating 2.5A
Wire Gauge 16-26 AWG
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 16 AWG
Wire/Cable Gauge 16 AWG
Number of Poles 15
Contact Current Rating 2.5A
Process Side Connection Terminal Blocks - Screw Connection
Control Side Connection D-Sub, Male
Control Side Cable Retainer Jackscrew Socket
Dimensions
Height 42mm
Length 2.559 65.00mm
Width 1.772 45.00mm
Compliance
RoHS Status RoHS Compliant
