39170-1034

Molex
RoHS
/
Package Module
Category Connectors, Interconnects / Terminal Blocks - Interface Modules
Description INTERFACE MOD HDR 34POS 12-26AWG
PDF
/
Inventory: 1313
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Width 92.456mm
Length 94.996mm

Technical

Fastening Method SCREW
Contact Rating (Current) 15A
Number of Ways 34
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Decks 2
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 26 AWG
Number of Circuits 34
Insulation Resistance 5GOhm
Current Rating 15A
Reach Compliance Code unknown
Orientation Vertical
Pitch 5.08mm
HTS Code 8536.69.40.40
Additional Feature POLARIZED, SHROUDED
Voltage - Rated 300V
Number of Rows 2
Color Black
ECCN Code EAR99
Part Status Discontinued
Published 2007

Physical

Housing Material Polyamide
Package / Case Module
Mounting Type BOARD
Contact Plating Tin
