0391702137
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Interface Modules
Description
POLARIZED SHROUDED Terminal Block Interface Module
PDF
/
Inventory: 6479
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type BOARD
Technical
Operating Temperature 110°C
Series Eurostyle 39170
Feature Component Area
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Rows 2
Voltage - Rated 300V
Additional Feature POLARIZED, SHROUDED
HTS Code 8536.69.40.40
Wire Gauge 12-26 AWG
Number of Decks 2
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Ways 37
Rated Current 15A
Process Side Connection Terminal Blocks - Header and Plug
Control Side Connection D-Sub, Male
Positions / Poles 37
Control Side Cable Retainer Jackscrew Socket
Current Rating (Per Contact) 15A
Dimensions
Length 4.189 106.40mm
Width 3.640 92.45mm
Compliance
RoHS Status ROHS3 Compliant
