1924650000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
WEIDMULLER 1924650000 TERMINAL BLOCK, PLUGGABLE, 5POS, 6AWG
PDF
/
Inventory: 2491
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Material Flammability Rating UL94 V-0
Technical
Stripping Length 12mm
Screw Size M4
Current - IEC 78.3A
Wire Gauge or Range - mm2 0.2-16mm2
Plug Wire Entry 180°
Safety Approval UL; CSA
Number of Ways 5
Torque - Screw 1.2-1.5 Nm (10.6-13.3 Lb-In)
Voltage - IEC 1kV
Current - UL 60A
Wire Gauge or Range - AWG 4-22 AWG
Number of Decks 1
Voltage - UL 600V
Contact Mating Finish Silver
Number of Poles 5
Wire/Cable Gauge 22 AWG
Number of Levels 1
Approval Agency CSA, cURus
Termination Style Screw - Clamping Yoke (Tension Sleeve)
Current Rating 61A
Insulation Height 1.205 30.61mm
Ingress Protection IP20
Pitch 0.400 10.16mm
Additional Feature STANDARD: UL 94V-0
Voltage - Rated 600V
Number of Rows 1
Color Black
Type Plug, Female Sockets
Connector Type Terminal Block
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Latch Lock, Mating Flange
Series Omnimate BU
Published 2008
Packaging Bulk
Operating Temperature -50°C~130°C
Physical
Housing Material Polyamide (PA), Nylon, Glass Filled
Insulation Material Nylon
Mounting Type Free Hanging (In-Line)
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
