1850940000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Omnimate SU RoHS Compliant IP20 Mating and Mounting Flange Terminal Block Header, Blade Pins, Shrouded (4 Side) UL94V-0 Vertical 60A 1kV
PDF
/
Inventory: 9769
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Housing Material Polybutylene Terephthalate (PBT), Glass Filled
Technical
Operating Temperature -50°C~120°C
Packaging Bulk
Series Omnimate SU
Feature Mating and Mounting Flange
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Header, Blade Pins, Shrouded (4 Side)
Color Black
Number of Rows 1
Gender Male
Voltage - Rated 300V
Additional Feature STANDARD: UL 94V-0
Pitch 0.400 10.16mm
Ingress Protection IP20
Insulation Height 1.260 32.00mm
Current Rating 54A
Termination Style Solder
Approval Agency cURus
Contact Tail Length 0.138 3.50mm
Number of Levels 1
Number of Poles 8
Contact Mating Finish Silver
Voltage - UL 300V
Number of Decks 1
Current - UL 60A
Voltage - IEC 1kV
Number of Ways 8
Safety Approval UL
Header Orientation Vertical
Current - IEC 78.3A
Hole Diameter 1.6 mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
