1842860000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Socket
PDF
/
Inventory: 5181
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Technical
Operating Temperature -50°C~100°C
Packaging Bulk
Series Omnimate SL
Feature Mating and Mounting Flange
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Header, Male Pins, Shrouded (4 Side)
Color Black
Number of Rows 1
Gender Male
Voltage - Rated 300V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Hole Diameter 1.4 mm
Current - IEC 15A
Header Orientation Vertical
Voltage - IEC 320V
Current - UL 10A
Voltage - UL 300V
Contact Mating Finish Tin
Number of Poles 11
Number of Levels 1
Contact Tail Length 0.126 3.20mm
Body/Shell Style PLUG
UL Flammability Code 94V-0
Approval Agency CSA, UR
Termination Style Solder
Current Rating 13A
Insulation Height 0.435 11.05mm
Ingress Protection IP10
Total Number of Contacts 8
Pitch 0.138 3.50mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
