1842630000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
WEIDMULLER 1842630000 Terminal Block, Header, 3.5 mm, 11 Ways, 15 A, 320 V, Through Hole Vertical
PDF
/
Buying Options
Total Price: USD $5.98
Unit Price: USD $5.975973
≥1 USD $5.975973
≥10 USD $5.637711
≥100 USD $5.318597
≥500 USD $5.017541
≥1000 USD $4.73353
Inventory: 1160
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Material Flammability Rating UL94 V-0
Technical
Hole Diameter 1.4 mm
Current - IEC 15A
Header Orientation Vertical
Safety Approval UL; CSA
Number of Ways 11
Voltage - IEC 320V
Current - UL 10A
Number of Decks 1
Voltage - UL 300V
Contact Mating Finish Tin
Number of Poles 11
Number of Levels 1
Contact Tail Length 0.126 3.20mm
Approval Agency CSA, UR
Termination Style Solder
Current Rating 12A
Insulation Height 0.435 11.05mm
Ingress Protection IP10
Pitch 0.138 3.50mm
HTS Code 8536.69.40.40
Additional Feature STANDARD: UL 94V-0
Voltage - Rated 300V
Gender Male
Number of Rows 1
Color Black
Type Header, Male Pins, Shrouded (4 Side)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Mating Flange, Solder Retention
Series Omnimate SL
Published 2015
Packaging Bulk
Operating Temperature -50°C~100°C
Physical
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 11 Weeks
