1804910000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
HIGH DENSITY Terminal Block Plug
PDF
/
Inventory: 1349
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Number of Levels 1
Number of Poles 22
Contact Mating Finish Tin
Voltage - UL 300V
Voltage - IEC 320V
Header Orientation Vertical
Current - IEC 15A
Hole Diameter 1.4 mm
Contact Tail Length 0.059 1.50mm
UL Flammability Code 94V-0
Approval Agency CSA, UR
Termination Style Solder
Current Rating 10A
Insulation Height 0.435 11.05mm
Ingress Protection IP10
Total Number of Contacts 22
Pitch 0.138 3.50mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature HIGH DENSITY
Voltage - Rated 300V
Gender Male
Number of Rows 1
Color Black
Type Header, Male Pins, Shrouded (4 Side)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Mating Flange, Solder Retention
JESD-609 Code e3
Series Omnimate SL
Packaging Bulk
Operating Temperature -50°C~100°C
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Physical
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
