1770780000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
TERM BLOCK PLUG 6POS 3.5MM
PDF
/
Inventory: 7866
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Free Hanging, Panel
Mounting Type Free Hanging (In-Line)
Housing Material Polybutylene Terephthalate (PBT)
Technical
Operating Temperature -50°C~80°C
Packaging Bulk
Published 2009
Series Omnimate BL
JESD-609 Code e3
Feature Mating Flange
Pbfree Code yes
Part Status Obsolete
Type Plug, Female Sockets
Number of Positions 6
Color Black
Number of Rows 1
Additional Feature HIGH DENSITY
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.138 3.50mm
Orientation Straight
Ingress Protection IP20
Insulation Height 0.492 12.50mm
Termination Style IDC
Number of Contacts 6
UL Flammability Code 94V-0
Voltage 300V
Number of Levels 1
Current 7A
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 20 AWG
Contact Mating Finish Tin
Wire Gauge or Range - AWG 20-22 AWG
Voltage - IEC 250V
Plug Wire Entry 90° and 270°
Wire Gauge or Range - mm2 0.35-0.5mm2
Current - IEC 6A
Dimensions
Height 12.5mm
Length 27.7mm
Width 21.2mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
