1747910000

Weidmüller
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Omnimate B2L RoHS Compliant 2002 Straight Terminal Block Plug, Female Sockets UL94V-0 22AWG -50C~100C 10A
PDF
/
Buying Options
Total Price: USD $42.01
Unit Price: USD $42.008861
≥1 USD $42.008861
≥210 USD $16.761794
≥510 USD $16.202499
≥990 USD $15.925477
Inventory: 5305
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Dimensions

Width 20.6mm
Length 59.5mm

Technical

Number of Positions Per Level 17
Current - IEC 10.3A
Wire Strip Length 7mm
Wire Gauge or Range - mm2 0.2-1mm2
Plug Wire Entry 180°
Voltage - IEC 200V
Wire Gauge or Range - AWG 16-28 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 22 AWG
Current 10A
Number of Levels 2
Max Current Rating 10A
Max Supply Voltage 150V
Voltage 150V
Insulation Resistance 1MOhm
Termination Style Screwless - Spring Cage, Tension Clamp
Insulation Height 0.618 15.70mm
Depth 20.6mm
Ingress Protection IP20
Orientation Straight
Total Number of Contacts 34
Pitch 0.138 3.50mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 2
Color Orange
Number of Positions 34
Type Plug, Female Sockets
Termination Crimp
Part Status Active
Pbfree Code yes
Series Omnimate B2L
Published 2002
Packaging Bulk
Operating Temperature -50°C~100°C

Physical

Housing Material Polybutylene Terephthalate (PBT)
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 12 Weeks
