1725330000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Omnimate SL RoHS Compliant GENERAL PURPOSE Lead Free Terminal Block Header, Male Pins, Shrouded (2 Side) UL94V-0 90° Right Angle 10A 300V
PDF
/
Inventory: 3585
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Housing Material Polybutylene Terephthalate (PBT)
Technical
Operating Temperature -50°C~100°C
Packaging Bulk
Series Omnimate SL
Pbfree Code yes
Part Status Active
Type Header, Male Pins, Shrouded (2 Side)
Color Orange
Number of Rows 2
Voltage - Rated 300V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.200 5.08mm
Total Number of Contacts 36
Insulation Height 1.032 26.21mm
Current Rating 17A
Termination Style Solder
Approval Agency CSA, UR
UL Flammability Code 94V-0
Voltage 300V
Contact Tail Length 0.126 3.20mm
Number of Levels 2
Current 10A
Number of Poles 36
Contact Mating Finish Tin
Voltage - IEC 400V
Positions Per Level 18
Header Orientation 90°, Right Angle
Current - IEC 17A
Hole Diameter 1.3 mm
Dimensions
Height 26.2mm
Length 94mm
Width 22.2mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
