1699420000

Weidmüller
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Terminal Block Header
PDF
/
Inventory: 7813
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Dimensions

Width 24.2mm
Height 22mm

Technical

Current - IEC 12A
Header Orientation 90°, Right Angle
Positions Per Level 11
Voltage - IEC 125V
Current - UL 10A
Voltage - UL 300V
Contact Mating Finish Tin
Number of Levels 2
Contact Tail Length 0.177 4.50mm
Insulation Resistance 1MOhm
Termination Style Solder
Insulation Height 0.866 22.00mm
Pitch 0.138 3.50mm
Color Black
Number of Positions 22
Type Header, Male Pins, Shrouded (4 Side)
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Mating and Mounting Flange
Series Omnimate SL
Packaging Bulk
Operating Temperature -50°C~130°C

Physical

Housing Material Polybutylene Terephthalate (PBT)
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy

Alternative Model
