1689220000
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Plug
PDF
/
Inventory: 6422
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mounting Type Free Hanging (In-Line)
Housing Material Polybutylene Terephthalate (PBT)
Technical
Operating Temperature -50°C~130°C
Packaging Bulk
Series Omnimate BL
Feature Retention Latches (Non-Wire Side)
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Type Plug, Female Sockets
Color Black
Pitch 0.200 5.08mm
Insulation Height 0.500 12.70mm
Termination Style Screwless - Spring Cage, Tension Clamp
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 12-22 AWG
Current - UL 10A
Voltage - IEC 125V
Plug Wire Entry 180°
Wire Gauge or Range - mm2 2.5mm2
Wire Strip Length 7mm
Current - IEC 12A
Number of Positions Per Level 8
Dimensions
Height 22.5mm
Width 12.7mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
