1671960000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
TERM BLOCK PLUG 4POS 5.08MM
PDF
/
Inventory: 4749
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Width 14.3mm
Length 20.3mm
Height 25.1mm
Technical
Fastening Method SPRING LOADED
Current - IEC 16.5A
Wire Strip Length 10mm
Wire Gauge or Range - mm2 0.2-2.5mm2
Plug Wire Entry 270°
Safety Approval UL; CSA
Number of Ways 4
Voltage - IEC 400V
Wire Gauge or Range - AWG 12-26 AWG
Number of Decks 1
Contact Mating Finish Tin
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 26 AWG
Current 10A
Number of Levels 1
Voltage 300V
Number of Contacts 4
Termination Style Screwless - Spring Cage, Tension Clamp
Insulation Height 0.563 14.30mm
Orientation Right Angle
Pitch 0.200 5.08mm
Number of Rows 1
Color Orange
Number of Positions 4
Type Plug, Female Sockets
ECCN Code EAR99
Termination Screwless
Part Status Active
Pbfree Code yes
Feature Retention Latches (Non-Wire Side)
Series Omnimate BL
Published 2009
Packaging Bulk
Operating Temperature -50°C~100°C
Physical
Housing Material Polybutylene Terephthalate (PBT)
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
