1635600000

Weidmüller
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Terminal Block Plug
PDF
/
Inventory: 985
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Technical

Number of Positions Per Level 12
Current - IEC 12A
Header Orientation 135°
Voltage - IEC 250V
Contact Mating Finish Tin
Current 15A
Number of Levels 1
Contact Tail Length 0.177 4.50mm
Voltage 300V
UL Flammability Code 94V-0
Lead Pitch 5.08mm
Termination Style Solder
Insulation Height 0.512 13.00mm
Total Number of Contacts 12
Pitch 0.200 5.08mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 1
Color Black
Number of Positions 12
Type Header, Male Pins, Shrouded (4 Side)
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code yes
Series Omnimate SL
Published 2002
Packaging Bulk
Operating Temperature -20°C~100°C

Physical

Housing Material Polybutylene Terephthalate (PBT)
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy
