1278350000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
TERM BLOCK PLUG 26POS STR 3.5MM
PDF
/
Buying Options
Total Price: USD $13.84
Unit Price: USD $13.8424
≥1 USD $13.8424
≥10 USD $13.28448
≥100 USD $12.82365
≥500 USD $12.36224
≥1000 USD $11.99323
≥3000 USD $11.762599
Inventory: 69
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper Alloy
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Insulation Material Nylon
Housing Material Polyamide (PA66), Nylon 6/6, Glass Filled
Technical
Operating Temperature -50°C~120°C
Packaging Bulk
Series Omnimate B2CF
Feature Ejector Latches
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screwless
ECCN Code EAR99
Type Plug, Female Sockets
Number of Positions 26
Color Black
Number of Rows 1
Voltage - Rated 50V
HTS Code 8536.69.40.40
Pitch 0.138 3.50mm
Ingress Protection IP20
Insulation Height 0.598 15.19mm
Current Rating 10A
Termination Style Screwless - Leg Spring, Push-In Spring
Voltage 300V
Number of Levels 2
Current 10A
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 16 AWG
Contact Mating Finish Tin
Wire Gauge or Range - AWG 16-26 AWG
Current - UL 9.5A
Voltage - IEC 320V
Positions Per Level 13
Plug Wire Entry 180°
Wire Gauge or Range - mm2 0.14-1.5mm2
Current - IEC 13.4A
Stripping Length 10mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
