1241760000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Unimate SLA RoHS Compliant GENERAL PURPOSE Male Terminal Block Header, Male Pins, Shrouded (4 Side) 90° Right Angle 10A 400V 0.370 9.40mm
PDF
/
Inventory: 8758
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Housing Material Polybutylene Terephthalate (PBT), Glass Filled
Technical
Operating Temperature -50°C~120°C
Packaging Bulk
Series Unimate SLA
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Header, Male Pins, Shrouded (4 Side)
Number of Positions 9
Color Orange
Number of Rows 2
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.200 5.08mm
Total Number of Contacts 9
Insulation Height 0.370 9.40mm
Termination Style Solder
Contact Tail Length 0.126 3.20mm
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Current - UL 10A
Voltage - IEC 400V
Header Orientation 90°, Right Angle
Current - IEC 17.5A
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
