1060910000

Weidmüller
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Terminal Block Header
PDF
/
Inventory: 5494
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Contact Material Copper Alloy
Mounting Type Free Hanging (In-Line)
Insulation Material Nylon
Housing Material Polyamide (PA), Nylon, Glass Filled

Technical

Operating Temperature -50°C~125°C
Packaging Bulk
Series Omnimate SV
Feature Mating Flange
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Plug, Blade Pins
Number of Positions 3
Color Black
Voltage - Rated 600V
Pitch 0.300 7.62mm
Ingress Protection IP20
Insulation Height 0.787 19.99mm
Current Rating 35A
Termination Style Screwless - Leg Spring, Push-In Spring
Approval Agency CSA, cURus
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 600V
Wire Gauge or Range - AWG 10-24 AWG
Voltage - IEC 1kV
Plug Wire Entry 180°
Wire Gauge or Range - mm2 0.5-10mm2
Current - IEC 41A
Stripping Length 12mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
