2-1986693-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
RoHS Compliant 2012 Lead Free Side Stacking Terminal Block Plug, Female Sockets 30AWG -40C~110C 9A 300V
PDF
/
Buying Options
Total Price: USD $68.48
Unit Price: USD $68.482177
≥1 USD $68.482177
≥200 USD $27.325388
≥500 USD $26.411609
≥1000 USD $25.961285
Inventory: 8608
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material Copper Alloy
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA), Nylon
Technical
Operating Temperature -40°C~110°C
Packaging Bulk
Published 2012
Feature Side Stacking
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screwless
ECCN Code EAR99
Connector Type Plug
Type Plug, Female Sockets
Color Green
Voltage - Rated 300V
HTS Code 8536.69.40.40
Pitch 0.138 3.50mm
Insulation Height 0.459 11.66mm
Current Rating 11A
Termination Style Screwless - Leg Spring, Push-In Spring
Voltage 300V
ELV Compliant
Max Current Rating 9A
Number of Levels 1
Current 9A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 14 AWG
Contact Mating Finish Tin
Wire Gauge or Range - AWG 14-30 AWG
Plug Wire Entry 180°
Wire Gauge or Range - mm2 0.05-2mm2
Number of Positions Per Level 25
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Lead Free Lead Free
