2-796641-0
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Pluggable Terminal Blocks 20P 5.0mm R/A PLUG
PDF
/
Inventory: 5768
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Material Bronze
Contact Plating Tin
Mount Cable, Free Hanging
Housing Material Polyamide
Technical
Packaging Box
Termination Screw
Connector Type Plug
Number of Positions 20
Color Black
Number of Rows 1
Voltage - Rated 300V
Pitch 5mm
Orientation Right Angle
Depth 18.4mm
Current Rating 15A
Voltage - Rated AC 300V
Number of Contacts 20
Housing Color Black
Voltage 300V
ELV Compliant
Number of Circuits 20
Number of Levels 1
Current 15A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 12 AWG
Thread Size M3
Number of Positions Per Level 20
Current Rating (Max) 15A
Max Supply Voltage (AC) 300V
Dimensions
Length 100mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
